GF30 - 3 t - 2 mot fr drive 4 wheels
Technical issues
| Max capacity | 3000 kg |
| Chassis dimensions (L x W x H) | |
| Steering radius | 1880 mm |
| Weight (about) | 3500 kg |
| Telescopic boom | Box boom, 4 sections, 2 section hydraulic, 1 section manual or hydraulic, 1 section manual. |
| Steering | Rear hydraulic steering |
| Tyres | 2 solid rear 15 x 4,5 - 8 and 4 solid front 18 x 7 - 8 |
| Drive system | Front with 2 motors on front axles, with counter rotation operated by high performance AC electronic controllers |
| Brakes | On front axle (on demand on rear axle) |
| Electrical option | Standard AC |
| Drive Motors | 2 kW x 2 (2 kW right front axle + 2 kW left front axle) |
| Power surce | 24V 600 Ah |
| Standard equipment | Digital safe load indicator with display, joystick-controlled proportional distributor, reversing alarm work light.Auto-levelling hydraulic system with front tool holder plate, forks (MULTIS version) |
| Optional equipment | Searcher hook, jib, forks, operator platform (MULTIS version), low marking tyres, radio remote control.Other equipment available |
